Numbers
- Global Incidence and Mortality
- Prevalent in all countries worldwide.
- 1/4 of the world's population has been infected with TB
- Only a portion will develop active disease.
- In 2020,
- 10 million people fell ill with TB
- 5.6 million were men
- 3.3 million were women
- 1.1 million were children.
- 1.5 million died
- 30 countries were identified as high TB burden countries,
- accounting for 86% of new TB cases,
- 8 of these countries contributing 2/3 of the total cases.
- Until the COVID-19 pandemic, TB was the leading cause of death from a single infectious agent globally.
- Geographical Distribution
- In 2020, the majority of TB cases were concentrated in the
- Southeast Asia (43%)
- Africa (25%)
- Western Pacific (18%)
- Eastern Mediterranean (8.3%)
- America (3.0%)
- Europe (2.3%)
- Number of total cases: India > China > Indonesia > Philippine > Pakistan > Nigeria > Bangladesh > South Africa.
- Increasing caseload in Brazil since 2015.
- Extrapulmonary and Skeletal TB
- Incidence of extrapulmonary TB has risen to 16% of total TB cases
- Up from an earlier 3%.
- Skeletal TB accounts for 10% of extrapulmonary cases.
- Spinal TB is the commonest (50% of all skeletal TB cases) musculoskeletal location
- Based on 2020 WHO data, if 16% of 7.1 million cases were extrapulmonary TB, then skeletal TB would account for roughly 0.1 million cases, with spinal TB comprising about 0.05 million cases.
WHO region | Total notified cases | Extrapulmonary cases (%) |
Africa | 1,436,330 | 15 |
The Americas | 250,341 | 15 |
Eastern Mediterranean | 506,641 | 24 |
Europe | 243,789 | 16 |
Southeast Asia | 3,641,245 | 19 |
Western Pacific | 1,416,592 | 8 |
Total (Globally) | 7,494,938 | 16 |
- Dynamics in Spinal TB Incidence (Last Decade)
- Globally, consistent decline in total TB cases over last 20 years,
- 1.7% per year reduction from 2000 to 2019,
- 1.9% reduction from 2019 to 2020.
- Due to changes in TB treatment protocols and national TB programmes.
- Despite the overall decline in total TB, the incidence of extrapulmonary TB has not significantly reduced compared to pulmonary TB, remaining relatively stable between 13% and 16% from 2010 to 2019.
- In European countries, an increasing number of TB incidence has been noted due to immigration from high-burden TB countries,
- with vertebral TB rising from 2.1% of all TB cases in 2004 to 5.8% in 2013.
- Spinal TB
- Developing nations: Burden of TB is significantly high
- India being a leading country among the 30 identified high-burden countries.
- Extrapulmonary TB and spinal TB are prevalent in most of these countries.
- Developed nations:
- Resurgence of spinal TB
- Due to immigration of individuals from TB-endemic regions.
- Over 50% of spinal TB cases occur among immigrant patients.
- Drug-Resistant Tuberculosis (DR-TB)
- MDR-TB is defined as Mycobacterium tuberculosis resistant to isoniazid and rifampicin, with or without resistance to other drugs.
- Extensively drug-resistant TB (XDR-TB) involves additional resistance to fluoroquinolones and at least one injectable second-line drug.
- Globally, an estimated 50 million people are infected with resistant strains of Mycobacterium tuberculosis.
- In 2018, about 3% of newly diagnosed TB patients (over 115,000) had MDR-TB.
- China and India together account for approximately 50% of all incident MDR-TB cases.
- The prevalence of MDR-TB
- Is higher in patients with previous anti-TB treatment (25–35%) VS
- Newly diagnosed patients (3.4%).
- Due to resistance to
- Isoniazid linked to katG or inhA gene mutations and
- Rifampicin resistance to rpoB gene point mutations.
- DR-TB can be
- Primary (acquiring a resistant strain) OR
- Acquired (conversion of a susceptible strain)
- due to
- Inadequate or poorly administered treatment regimens
- Widespread use of certain antibiotics in the community
- HIV and TB Co-infection
- TB is the most prevalent opportunistic infection in people living with HIV (PLHIV)
- TB is the most common presenting illness in newly diagnosed HIV patients.
- Since 2000, while global TB incidence declined by 1.4% annually, the number of cases grew to 10.4 million in 2015, with 11% having HIV infection.
- The majority of TB/HIV cases are found in
- Sub-Saharan Africa
- Former Soviet Union nations.
- HIV-positive individuals are 26 times more likely to develop active TB than HIV-negative individuals,
- Contributing to a global increase in the HIV–TB syndemic.
- In South Africa, 40–80% of patients with MDR-TB and XDR-TB are HIV positive.
- HIV and M. tuberculosis exhibit a "synergistic convergence" or "syndemic,"
- where active TB increases the risk of HIV-related mortality and boosts viral loads.
- M. tuberculosis infection can enhance HIV replication in CD4 T cells and macrophages through various pathways, including stimulating proinflammatory responses via Toll-like receptors and NOD2, which promotes HIV transcription.
- Those with significant immune suppression due to HIV are more likely to develop extrapulmonary TB.
- Spinal TB is a common co-infection, accounting for 68% of myelopathy or cauda equina syndrome cases in high HIV–TB co-infection settings where an etiological cause was proven.
- HIV-positive individuals + spinal TB
- may show less vertebral body collapse despite similar numbers of affected bodies compared to HIV-negative patients, due to an altered local inflammatory response.
- They often present with larger epidural pus collections.
- At risk for atypical locations of TB infection, such as isolated posterior element involvement.
Pathogenesis
- Initial Infection and Primary Focus Formation
- Airborne bacilli released by an individual with active TB disease → Mycobacterium tuberculosis acquired via inhalation → the bacilli are phagocytosed by alveolar macrophages in the lungs →
- Immune Response & Primary Complex: The bacilli are then transported by these macrophages to the regional lymph nodes, where an adaptive immune response is generated. The lungs are the most common primary focus of infection, though less commonly, lymph nodes, the gastrointestinal tract, and the genitourinary tract may also be involved.
- Progression from Infection to Disease (Latent vs. Active)
- Approximately one-quarter of the world's population has been infected with TB. However, it's important to note that only a portion of these individuals will develop active disease. Those who develop active disease are capable of transmitting TB. This implies a latent phase where the infection is contained but not eradicated.
- Dissemination to the Spine (Secondary Infection)
- Spinal TB is almost always secondary to an active or latent infection at an extraspinal primary focus.
- The primary route of spread to the spine is hematogenous dissemination (via the bloodstream), either through arterial or venous pathways. Lymphatic drainage is also a possible transmission route.
- Spinal Predilection: The cancellous region of the spine has a predilection for TB infection due to the abundant vasculature from the anterior and posterior spinal arteries, which form a rich vascular anastomosis near the subchondral region. Most spinal TB infections begin at the subchondral bone of the vertebral bodies because the paradiskal arteries split on either side of the disk.
- Types of Spinal Lesions and Vertebral Destruction
- Once the bacilli reach the spine, they typically lodge in the paradiskal, subchondral region of the vertebral body in over 90% of cases.
- Bacillar enzymes and the patient's inflammatory granulomatous response lead to the progressive destruction of the vertebral body on either side of the disk.
- Spinal lesions in Pott's spine (spinal TB) are classified based on their location
- Paradiskal: This is the most common type. It involves adjacent vertebrae, initially sparing the disk, but later involving the disk space. Radiographically, it appears as irregular endplates, disk space narrowing, and bone destruction in later stages.
- Central: Characterized by vertebral body involvement while initially sparing the disk space. Later, the vertebrae can collapse, leading to vertebra plana, or mimic tumours due to ballooning of the posterior cortex. The spread in this type is thought to be from the valveless Batson's venous plexus or posterior vertebral artery.
- Anterior: Involves the anterior and lateral parts of the vertebral body. The infection starts anteriorly behind the anterior longitudinal ligament and periosteum, leading to destruction due to deprivation of blood supply. This type is more common in the thoracic spine in children, often showing anterior scalloping of the vertebral body.
- Posterior (Appendiceal): Less common, involving posterior elements like pedicles, laminae, transverse processes, and spinous processes. Radiographically, it appears as erosive lesions and paravertebral abscesses with an intact disk space. More appendiceal TB cases are identified with the advent of CT and MRI.
- Nonosseous: Characterised by a large paravertebral abscess with minimal bone involvement, commonly seen in the lower lumbar and sacroiliac regions.
- Noncontiguous vertebral lesions can also occur, with spread thought to be from Batson's paravertebral venous plexus during strenuous activities like coughing.
- Cold Abscess Formation and Spread
- A characteristic feature of TB, cold abscesses develop when the infection spreads to surrounding ligaments and soft tissue. They are "cold" because they lack the typical signs of inflammation like pain.
- These abscesses can vary in size and consist of fluid pus, granulation tissue, or caseous material.
- Their location and spread depend on the affected vertebral region, typically tracking along neurovascular or natural fascial planes of least resistance. Examples include
- Cervical spine: Spread to retropharyngeal space, anterior/posterior cervical triangle, mediastinum, or axilla.
- Thoracic spine: Track along intercostal spaces to present as chest wall swelling, paraspinal swelling, or track through the arcuate ligament to form lumbar abscesses.
- Lumbosacral spine: Track through the psoas sheath to the iliac fossa, behind the inguinal ligament to the proximal thigh (Scarpa's triangle), or to the gluteal region.
- Potential Neurological Involvement
- Neurological deficits can occur in early (active disease) or late (healed) stages.
- Early neurological deficits are primarily due to compression by an abscess, inflammatory/granulation tissue, or sequestrum. Mechanical compression can also arise from vertebral body destruction, subluxation/dislocation, and kyphosis. Inflammatory cord edema or infarction of the cord (due to endarteritis or thrombosis) can also lead to early deficits.
- Delayed neurological deficits can occur due to the stretch of the spinal cord over an internal gibbus (kyphosis). Preexisting factors like ossified ligamentum flavum (OLF), ossification of the posterior longitudinal ligament (OPLL), or spinal stenosis can exacerbate or predispose to neurological deficits.
- The progression typically involves the anterior column first, then the lateral column, and finally the posterior column in severe cases.
- Kyphosis Development
- Spinal TB preferentially affects the ventrally placed vertebral bodies, making kyphosis an eventual outcome of the disease.
- As the disease progresses, vertebral endplates weaken, allowing for herniation or ballooning of the intervertebral disk into the vertebral body.
- In the thoracic spine, where there is natural kyphosis and weight transmission is mainly through the anterior column, destruction of the anterior half of the vertebral body leads to progressive kyphosis. The severity of kyphosis depends on the number of levels affected, bone loss, and spinal region.
- In children, kyphosis can progress even after the disease is healed.
This detailed cascade, from initial airborne exposure to eventual spinal involvement and its potential complications, outlines the complex pathogenesis of tuberculosis leading to spinal disease.
- To be sorted
- Spinal tuberculosis - The Lancet
- Current Trends in the Management of Spine TB - Dr Ajoy Shetty
- Pott’s disease - 1% of total TB cases
- Slower course/ presentation - night sweats/ weight loss
- Consider patient age/ ethnicity/ other clinical symptoms
- Thoracic location
- More than 2 levels, skip lesions
- Large paravertebral collections
- Deformity
- Extensive bone destruction
- Relative disc sparing early on
- TB work up - CT CAP – usually pulmonary origin
- Indication for spinal biopsy? Target other areas first?
- Medical management – 6–12 months
- RIPE (Rifampin + Isoniazid + Pyrazinamide ± Ethambutol)
- Indication for surgery?
- >30 kyphosis at presentation
- >60 kyphosis at any point
- Progressive deficit
- Pain
- Refractory to medical management
- Large abscess
Tuberculosis is the most common granulomatous infection of the spine. The three patterns of spinal involvement are peridiscal (commonest), central, and anterior. Peridiscal occurs adjacent to the vertebral endplate and spreads around a single intervertebral disc as the abscess material tracks beneath the anterior longitudinal ligament (the disc is usually spared unlike in pyogenic infections). Central involvement occurs in the middle of the vertebral body and eventually leads to vertebral collapse and kyphotic deformity. This pattern of involvement can be mistaken for a tumor. Anterior infections begin beneath the anterior longitudinal ligament, causing scalloping of the anterior vertebral bodies, and extend over multiple levels. The presentation is highly variable. Mild back pain is the most common symptom. Patients with tuberculous infections may present with malaise, fevers, night sweats, and weight loss. In addition, chronic infections may result in cutaneous sinuses, neurologic deficits (in up to 40% of patients), and kyphotic deformities. Certain factors define the high-risk population and should raise suspicion. Patients from countries with a high incidence of tuberculosis, such as Southeast Asia, South America, and Russia are considered high risk. Patients who live in confinement with others, such as homeless centers and prisons, are also at risk. Elderly adults, chronic alcoholics, patients with AIDS, and patients with a family member or a household contact with tuberculosis are additional high-risk groups. The leukocyte count may be normal or mildly elevated. The ESR is mildly elevated (typically < 50), but may be normal in up to 25% of cases. Although the purified protein derivative (PPD) skin test may detect active infection or past exposure, this test is unreliable because false-negative results may occur in malnourished and immunocompromised patients. Anergy panel testing should be included for this reason. Urine cultures, sputum specimens, and gastric washings may be helpful for diagnosis if the primary source is unknown. The most reliable test for diagnosis is CT-guided biopsy. The characteristic finding on histology is a granuloma, which is described as a multinucleated giant-cell reaction surrounding a central region of caseating necrosis. Molecular detection of mycobacterium DNA or RNA is useful for rapid diagnosis and for determining drug resistance. Radiographs: A clue to diagnosis is the presence of extensive vertebral destruction out of proportion to the amount of pain. Typically, the intervertebral discs are preserved in the early stages of this disease. Chest radiographs can be useful in demonstrating pulmonary MRI: The imaging modality of choice for diagnosis of spinal TBCT: Plays a role in defining the extent of bony destruction and localization for biopsies. Chemotherapy (four-drug regimen, for a minimum of 6-month duration, includes isoniazid, rifampin, pyrazinamide, and ethambutol) and brace immobilization are the initial treatment except in patients presenting with neurologic deficit or progressive deformity. The indications for surgery and the principles of surgical reconstruction are similar to those advised for pyogenic spinal infections.
