Neurosurgery notes/Tumours/Melanocytic tumours/Circumscribed meningeal melanocytic neoplasms: Melanocytoma and melanoma

Circumscribed meningeal melanocytic neoplasms: Melanocytoma and melanoma

View Details
Status
Done

General

  • Circumscribed meningeal melanocytic neoplasms arise from leptomeningeal melanocytes and range histologically from well-differentiated tumours (meningeal melanocytoma) to frankly malignant neoplasms with aggressive growth properties (meningeal melanoma).
graph LR A["Leptomeningeal<br>melanocytes"] --> B["Meningeal melanocytoma"] --> C["Melanocytoma of<br>intermediate grade"] --> D["Meningeal melanoma"]
  • Meningeal melanocytomas with increased mitotic activity or invasion of the CNS parenchyma have been defined as melanocytoma of intermediate grade.

Definition

Meningeal Melanocytoma

  • Essential:
    • Circumscribed/localized primary melanocytic neoplasm in the meninges.
    • Limited cytological atypia, (almost) no mitoses, no necrosis, and (in cases of evaluable CNS parenchyma) no CNS invasion.
  • Desirable:
    • Demonstration of GNAQ, GNA11, PLCB4, or CYSLTR2 mutation corroborates the CNS origin of the neoplasm, especially after exclusion of uveal or blue naevus-like melanoma.
    • Additional molecular markers (SF3B1, EIF1AX, and BAP1 mutations; chromosome 3 monosomy; complex copy-number variations) indicating aggressive behaviour.

Intermediate-grade Melanocytoma

  • Essential:
    • Circumscribed/localized primary melanocytic neoplasm in the meninges.
    • Mitotic count of 0.5–1.5 mitoses/mm2 and/or CNS invasion, but limited cytological atypia and no necrosis.
  • Desirable:
    • Demonstration of GNAQ, GNA11, PLCB4, or CYSLTR2 mutation corroborates the CNS origin of the neoplasm, especially after exclusion of uveal or blue naevus-like melanoma.
    • Additional molecular markers (SF3B1, EIF1AX, and BAP1 mutations; chromosome 3 monosomy; complex copy-number variations) indicating aggressive behaviour.

Meningeal Melanoma

  • Essential:
    • Circumscribed/localized primary melanocytic neoplasm in the meninges.
    • Mitotic count * > 1.5 mitoses/mm2* and/or necrosis, often accompanied by marked cytological atypia.
  • Desirable:
    • Demonstration of GNAQ, GNA11, PLCB4, or CYSLTR2 mutation corroborates the CNS origin of the neoplasm, especially after exclusion of uveal or blue naevus-like melanoma.
    • Additional molecular markers (SF3B1, EIF1AX, and BAP1 mutations; chromosome 3 monosomy; complex copy-number variations) indicating aggressive behaviour.

Numbers

  • Meningeal melanocytomas and melanomas are rare, accounting for 0.06–0.1% of meningeal tumours.
    • Both can occur at any age, but they are most frequent in the fourth and fifth decades of life.
  • Meningeal melanocytomas
    • Incidence of 1 case per 10 million person-years.
    • Slight female predominance: 1.5:1
    • Mean age of diagnosis: 45.6 years (range: 23–69 years)
  • Meningeal melanomas
    • Annual incidence of 0.005 cases per 100 000 population.
    • Mean age of diagnosis: 53.7 years (range: 15–86 years)
      • The mean age at diagnosis of meningeal melanoma was 48.5 years for adults and 5.4 years (median: 3.0 years) for children.

WHO grade

  • Meningeal melanocytoma is generally well-differentiated, reflecting a low-grade lesion, but it is not assigned a WHO CNS grade to melanocytoma itself.
  • Meningeal melanomas are frankly malignant neoplasms.
  • Tumours with bland histological appearance but increased mitotic activity or invasion of the CNS parenchyma are defined as melanocytoma of intermediate grade.

Histopathology

Macroscopic

  • Meningeal melanocytomas and melanomas are circumscribed mass lesions that may be black, reddish-brown, blue, or macroscopically non-pigmented, depending on the melanin content.
Fig. 12.05 Spinal meningeal melanoma with diffuse infiltration of the leptomeninges and focal infiltration of the medulla.
Spinal meningeal melanoma with diffuse infiltration of the leptomeninges and focal infiltration of the medulla.

Microscopic

Meningeal Melanocytoma

  • Tumours show a spectrum of histopathological features ranging from bland-appearing, low-grade, well-differentiated melanocytomas to overtly malignant melanomas.
  • Well-differentiated melanocytomas may show variable (sometimes high) cell density and are usually composed of densely packed, slightly spindled or oval tumour cells containing variable (at times abundant) melanin.
  • Tumour cells may form tight nests with a superficial resemblance to the whorls of meningioma.
  • Other patterns seen rarely include storiform, vasocentric, or sheet-like arrangements.
  • The nuclei are oval or bean-shaped, occasionally showing grooves, with small eosinophilic nucleoli.
  • Cytological atypia, necrosis, and mitoses are generally absent (on average < 0.5 mitoses/mm2).
  • Melanocytomas generally do not show invasion of CNS parenchyma.
Images
Fig. 12.04 Meningeal melanocytoma. A Loose or tight nests Of low-grade, pigmented spindle cells with intervening stroma containing higher levels Of melanin pigment. Note the vague, loosely formed whorls and fascicles. B Accumulation Of large, melanin-containing macrophages (melanophages) seen between turnour cells with a more spindled phenotype. The nuclei of tumour cells are bean-shaped and have micronucleoli. Melanin within the cytoplasm Of melanophages is typical in larger aggregates. C Melanin-containing macrophages (melanophages).
Loose or tight nests of low-grade, loosely formed spindle cells with intervening stroma containing higher levels of melanin pigment. Note the vague, loosely formed whorls and fascicles.
Fig. 12.04 Meningeal melanocytoma. A Loose or tight nests Of low-grade, pigmented spindle cells with intervening stroma containing higher levels Of melanin pigment. Note the vague, loosely formed whorls and fascicles. B Accumulation Of large, melanin-containing macrophages (melanophages) seen between turnour cells with a more spindled phenotype. The nuclei of tumour cells are bean-shaped and have micronucleoli. Melanin within the cytoplasm Of melanophages is typical in larger aggregates. C Melanin-containing macrophages (melanophages).
Accumulation of large, melanin-containing macrophages (melanophages) is seen between tumour cells with a more spindled phenotype. The nuclei of tumour cells are bean-shaped and have micronucleoli. Melanin within the cytoplasm of melanophages is typical in larger aggregates.
Fig. 12.04 Meningeal melanocytoma. A Loose or tight nests Of low-grade, pigmented spindle cells with intervening stroma containing higher levels Of melanin pigment. Note the vague, loosely formed whorls and fascicles. B Accumulation Of large, melanin-containing macrophages (melanophages) seen between turnour cells with a more spindled phenotype. The nuclei of tumour cells are bean-shaped and have micronucleoli. Melanin within the cytoplasm Of melanophages is typical in larger aggregates. C Melanin-containing macrophages (melanophages).
Melanin-containing macrophages (melanophages).

Intermediate-grade Melanocytoma

  • These exhibit the histology of melanocytoma but show CNS invasion or increased mitotic activity (0.5–1.5 mitoses/mm2).

Meningeal Melanoma

  • Melanomas are more pleomorphic and mitotically active, and they may have a high cell density.
  • Histologically similar to melanomas arising in other sites.
  • Unequivocal invasion of the CNS parenchyma or coagulative necrosis.
  • Melanomas may be composed of pleomorphic spindled or epithelioid cells (arranged in loose nests, fascicles, or sheets) and display variable cytoplasmic melanin.
  • Some melanomas contain large cells with bizarre nuclei, numerous (typical and atypical) mitotic figures, and large nucleoli.
  • Others are highly cellular and less pleomorphic, consisting of smaller, tightly packed spindle cells with a high N:C ratio.
  • Pleomorphic, anaplastic, and mitotically active, and have a higher cell density, than melanocytoma
Fig. 12.06 Thoracic meningeal melanoma. The epithelioid and spindled tumour cells have ample, eosinophilic cytoplasm and a large vesicular nucleus with prominent nucleolus, and show marked mitotic activity (arrows). Dispersed melanophages are present between the tumour cells; in this tumour, a GNAII mutation was identified.
Thoracic meningeal melanoma. The epithelioid and spindled tumour cells have ample, eosinophilic cytoplasm and a large vesicular nucleus with prominent nucleolus, and show marked mitotic activity (arrows). Dispersed melanophages are present between the tumour cells; in this tumour, a GNA11 mutation was identified.

Immunophenotype

  • All meningeal melanocytic tumours strongly express S100, vimentin, melan-A (MART1), HMB45, and MITF.
  • Meningeal melanomas may show loss of BAP1 expression, detected immunohistochemically.

Genetic features

  • Two steps in oncogenesis of meningeal melanocytic tumours not associated with neurocutaneous melanosis.
      1. First step: Mutations in GNAQ, GNA11, PLCB4, or CYSLTR2
          • GNAQ and GNA11 mutations at codon 209
            • are the most frequent, found in about 60–70% of cases.
            • Similar to those present in uveal melanoma and blue naevus
            • Present in Primary CNS melanomas but much lower fq than melanocytomas.
          • These mutations impair GTPase activity, leading to constitutive activation of downstream intracellular pathways, including the RAF/MEK/ERK and Hippo/YAP1 signalling pathways, which regulate cell growth and proliferation.
      1. Second step: EIF1AX, SF3B1, or BAP1 mutation
          • Higher incidence reported in melanomas.
          • BAP1 is a tumour suppressor gene, and loss-of-function hemizygous mutations combined with chromosome 3 monosomy result in decreased or absent BAP1 protein expression.
  • Chromosomal changes
    • Chromosomal alterations may include
      • Gains of chromosome arms 8q and 6p
      • Loss of chromosome arms 1p and 6q
      • Monosomy of chromosome 3.
    • Meningeal melanomas usually have a more complex copy-number variation profile, with multiple large chromosomal gains and/or losses.
  • Childhood meningeal melanomas in patients with neurocutaneous melanosis typically harbour NRAS mutations.
    • NRAS mutations
      • Occurs in
        • Cutaneous naevi for adults
        • CNS melanocytic neoplasms for children
          • If you see there is NRAS mutation in CNS melanocytic neoplasm in adults it is most likely a metastatic lesion
      • Involving codon 61
      • Not inherited But
        • Occurs early in embryogenesis → melanocyte precursors migrate to skin and leptomeninges
        • Hence it is Monoclonal
  • BRAF V600E mutations
    • Occurs in
      • Cutaneous naevi of patients with neurocutaneous melanosis (albeit less frequently)
    • Does not occur in CNS melanocytic neoplasms
  • Tumour progression to melanoma
    • Similar to uveal melanoma
      • Early mutations
        Late mutations
        GNAQ mutation or
        GNA11 mutations
        BAP1 inactivation or
        SF3B1 mutation or
        EIF1AX mutation
  • Differentiating primary vs Metastatic disease
    • Presence of TERT promoter, NRAS, BRAF, and KIT, are rare in primary CNS melanocytic neoplasms of adults, and when encountered raise suspicion of a metastasis.

Localisation

  • Meningeal melanocytomas
    • Extramedullary, intradural compartment at the cervical and thoracic spine.
      • Can be dural-based or associated with nerve roots or spinal foramina
      • Less frequently, they arise from the leptomeninges in the posterior fossa or supratentorial compartments.
        • Trigeminal cave
          • A site with a peculiar predilection for primary melanocytic neoplasms, and tumours at this site are associated with an ipsilateral naevus of Ota
  • Meningeal melanomas
    • may occur throughout the neuraxis, but they show a predilection for the spinal canal and posterior fossa.
  • A purely intraparenchymal location of a melanoma in the CNS is highly indicative of metastatic disease.

Clinical features

  • Patients mostly present with symptoms related to compression of the spinal cord, cerebellum, or cerebrum by an extra-axial mass, with focal neurological signs depending on location.
  • Distant metastasis from meningeal melanocytic tumours, mostly melanomas, are rare (reported in liver, bone, and lungs).

Radiological features

  • CT
    • Well-defined
    • Isodense to hyperdense
    • Homogenous
    • Contrast enhancing lesion
  • MRI
    • On MRI, they often show T1 hyperintensity due to the paramagnetic properties of melanin pigment, and they are typically isointense to hypointense on T2-weighted images.
    • Meningeal melanocytomas and melanomas are isoattenuating to hyperattenuating, contrast-enhancing on CT, with an imaging appearance similar to that of meningiomas but usually without hyperostosis or intratumoural calcification.
    • CNS structures adjacent to a meningeal melanoma are often T2-hyperintense due to vasogenic oedema.
    • Variable depending on the amount of melanin content present.
    • Signal characteristics include:
      • T1: isointense or hyperintense
      • T2: isointense or hypointense
      • T1 C+ (Gd): heterogeneous enhancement
      • T2* GRE: may show blooming of low signal.
      Images
      ig. 12.03 MRI features Of meningeal melanocytoma. A Tl-weighted axial images (pre-contrast) reveal a hyperintense, well-circumscribed mass in the midline Of the cerebellum rising from the dura. B On T2-weighted images, the mass is hypointense. C Following the administration Of contrast agent, the melanocytoma shows homogeneous enhancement.
      T1-weighted axial images (pre-contrast) reveal a hyperintense, well-circumscribed mass in the midline of the cerebellum arising from the dura.
      ig. 12.03 MRI features Of meningeal melanocytoma. A Tl-weighted axial images (pre-contrast) reveal a hyperintense, well-circumscribed mass in the midline Of the cerebellum rising from the dura. B On T2-weighted images, the mass is hypointense. C Following the administration Of contrast agent, the melanocytoma shows homogeneous enhancement.
      On T2-weighted images, the mass is hypointense.
      ig. 12.03 MRI features Of meningeal melanocytoma. A Tl-weighted axial images (pre-contrast) reveal a hyperintense, well-circumscribed mass in the midline Of the cerebellum rising from the dura. B On T2-weighted images, the mass is hypointense. C Following the administration Of contrast agent, the melanocytoma shows homogeneous enhancement.
      Following the administration of contrast agent, the melanocytoma shows homogeneous enhancement.

Prognosis

  • The clinical behaviour correlates with histopathological features.
    • Melanocytomas typically lack anaplastic features, but local recurrence or leptomeningeal seeding occur in some patients, with intermediate-grade melanocytic tumours seeming more recurrence prone.
  • Malignant transformation of a melanocytoma (Intermediate-grade melanocytic tumours) and metastatic spread outside the CNS have been reported.
  • Meningeal melanoma is usually a highly aggressive and radioresistant tumour with a poor prognosis.
  • The prognosis tends to be better for patients with primary meningeal melanoma (particularly if complete resection of the primary tumour can be achieved) than for patients with CNS metastasis of cutaneous melanoma.
  • Some meningeal melanocytic tumours (EIF1AX, SF3B1, and BAP1 mutations; chromosome 3 monosomy; or complex copy-number variations) show aggressive clinical behaviour.
  • The prognosis for NRAS-mutant meningeal melanoma in children is very poor.
